Delta ModTech and Frontier LLC have officially merged. Read More →

Coating and Drying Systems

Designing, building and optimizing high quality coating lines and drying ovens for 30 years.

DynaCoat®

This turn-key coating system has a small footprint and is a perfect fit for lab scale, pilot scale or production coating.

DynaCoat® XL

This turn-key coating system has a small footprint and is a perfect fit for lab scale, pilot scale or production coating.

Lab Scale

Our proven coating technologies provide the flexibility needed for lab environments.

We are committed to delivering the best solution for your production goals.


  • Batteries
  • Capacitors
  • Textile & Adhesive
  • Paper, Film & Foil
  • Fuel Cells
  • Transdermal Patches
  • Oral Pharmaceuticals
  • Medical Diagnostics
  • Microelectronics

Machines for the manufacturing of:


  • Slot Die with WebFlight™
  • Rotogravure
  • Direct / Offset Coating
  • Patch Coating (Slot Die)
  • Mayer Rod
  • Reverse / Direct Roll
  • Knife-over-roll
  • Stripe Coating (Slot Die)
  • Comma
  • Extrusion

Available Coating Technologies


  • Hazardous Duty Rating
  • Clean Room Features
  • Single/Multi-Slot Dies
  • Cascade Dies
  • Fluid Delivery
  • Winders and Laminators

Design / Build Services for:


  • Flotation oven drying
  • Infrared curing
  • Roll Support drying
  • Ultraviolet curing
  • Impinged Air
  • EBeam

Learn more more about our drying and curing ovens.

Drying and Curing Options


Max Web Width:254 mm (10 in), 330 mm (13 in), 508 mm (20 in), 609 mm (24 in), 762 mm (30 in), 1016 mm (40 in), 1270 mm (50 in), 1702 mm (67 in), 2000 mm (79 in)
Min Web Width:76 mm (3 in)
Min Coating Width:50 mm (0.5 in)
Coating Thickness (Slot Die):Down to 2 micron
Unwind/Rewind Mandrel Diameter:26 mm (1 in), 76 mm (3 in), 153 mm (6 in)
Line Speed Range:Process dependent
Control System:Delta ModTech INTELLI-MOD® control system
Drive System:Servomotor Control
Temperature Control:Independent zone controlled
Temperature Range:Ambient Temp. up to 204° C (400° F)*
Oven Length:1 m (3 ft) up to 100 m (300 ft)
Construction:Stainless steel
Heating Source:Electric, Gas, Steam

* Solvent type and dryer loading may limit maximum temperature capability.

Coating and Drying Specifications

Contact us to learn more about scheduling a lab trial or for a list of qualified contract coaters.

Whether we’re answering some introductory questions or if you’re in need of a quote, just fill in the form or call us at 1-800-279-3358 and we can get you the answers you need.
