Coating and Drying Systems
Designing, building and optimizing high quality coating lines and drying ovens for 30 years.
We are committed to delivering the best solution for your production goals.
- Batteries
- Capacitors
- Textile & Adhesive
- Paper, Film & Foil
- Fuel Cells
- Transdermal Patches
- Oral Pharmaceuticals
- Medical Diagnostics
- Microelectronics
Machines for the manufacturing of:
- Slot Die with WebFlight™
- Rotogravure
- Direct / Offset Coating
- Patch Coating (Slot Die)
- Mayer Rod
- Reverse / Direct Roll
- Knife-over-roll
- Stripe Coating (Slot Die)
- Comma
- Extrusion
Available Coating Technologies
- Hazardous Duty Rating
- Clean Room Features
- Single/Multi-Slot Dies
- Cascade Dies
- Fluid Delivery
- Winders and Laminators
Design / Build Services for:
- Flotation oven drying
- Infrared curing
- Roll Support drying
- Ultraviolet curing
- Impinged Air
- EBeam
Learn more more about our drying and curing ovens.
Drying and Curing Options
| Max Web Width: | 2000 mm (79 in) |
| Min Web Width: | 76 mm (3 in) |
| Min Coating Width: | 50 mm (0.5 in) |
| Coating Thickness (Slot Die): | Down to 2 micron |
| Unwind/Rewind Mandrel Diameter: | 26 mm (1 in), 76 mm (3 in), 153 mm (6 in) |
| Line Speed Range: | Process dependent |
| Control System: | Delta ModTech INTELLI-MOD® control system |
| Drive System: | Servomotor Control |
| Temperature Control: | Independent zone controlled |
| Temperature Range: | Ambient Temp. up to 204° C (400° F)* |
| Oven Length: | 1 m (3 ft) up to 100 m (300 ft) |
| Construction: | Stainless steel |
| Heating Source: | Electric, Gas, Steam |
* Solvent type and dryer loading may limit maximum temperature capability.
Coating and Drying Specifications
Contact us to learn more about scheduling a lab trial or for a list of qualified contract coaters.
