DynaCoat®
Compact coating and drying system
This turn-key coating system has a small footprint and is a perfect fit for lab scale, pilot scale or production coating.
Flexibility
Cost Savings
Compact Footprint
About the DynaCoat®
Roll to Roll Coating Solutions For:
- Microelectronics
- Medical Diagnostics
- Transdermals
- Oral Pharmaceuticals
- Batteries and Capacitors
- Fuel Cells
- Textile & Adhesive
- Film & Foil
Available Coating Technologies
- Slot Die with Webflight™ Technology
- Patch, Pattern, Stripe Coating
- Gravure
- Direct/Offset Coating
- Mayer Rod
- Roll Coaters – Reverse/Direct
- Knife-over-roll
- Comma Coating
Options
- Dual and triple layer slot die coating capability
- Patch or skip coating capability
- 2 Zone Infrared Preheat
- Interleaf unwind and rewind spindles
- Laminator Assembly
- Corona Treater
DynaCoat® Standard Technical Specifications
Web Width: | 76 mm to 330 mm (3 in to 13 in) |
Coating Width: | 50 to 305 mm (2 in to 12 in) |
Coating Thickness (Slot Die): | Down to 2 micron |
Full Roll Diameter: | 559 mm (22 in) Unwind, 152 mm (16 in) Rewind(s) |
Unwind/Rewind Mandrel Diameter | 76 mm (3 in) standard, other sizes available |
Line Speed Range: | Process dependent |
Control System: | Delta ModTech INTELLI-MOD® control system |
Drive System | Servomotor Control |
DynaCoat Dimensions: | 2.2 m H x 3.0 m L x 1.9 m W (86 in x 120 in x 74 in) |
DynaCoat XL Dimensions: | 2.2 m H x 4.0 m L x 1.9 m W(86 in x 156 in x 74 in) |
Drying: | Hot Air Impingement |
Temperature Control: | 8 independent set points [12 on DynaCoat XL] |
Temperature Range: | Room temp to 149º C (300º F) |
* Solvent type and dryer loading may limit maximum temperature capability.
Contact us to learn more about scheduling a lab trial or for a list of qualified contract coaters.
